ECS H61H2-I5 User Manual

H61H2-I5 USER MANUAL
Chapter 1
5
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1155 socket for Intel® Sandy/Ivy Bridge Processors
2. PCIEX16 PCI Express slot for graphics interface
3. F_AUDIO Front panel audio header
4. USBPWR_R Rear USB/PS2 power select jumper
5. CPU_FAN 4-pin CPU cooling fan connector
6. SYS_FAN 3-pin system cooling fan connector
7. ATX12V1 4-pin +12V power connector
8. VGA_HEADER VGA header (Optional)
9. F_PANEL Front panel switch/LED header
10. SATA1~4 Serial ATA 3.0 Gb/s connectors
11. SPK Speaker header
12. CASE Case open header
13. CLR_CMOS Clear CMOS jumper
14. F_USB2 Front panel USB 2.0 header
15. USBPWR_F Front Panel USB power select jumper
16. F_USB1 Front panel USB 2.0 header
17. COM Onboard serial port header
18. ATX_POWER Standard 24-pin ATX power connector
19. DDR3_1~2 240-pin DDR3 Module slots
20. ME_UNCLOCK ME Unlock header-for factory use only
