H61H2-I5 USER MANUAL

Chapter 2

CPU Ratio (31)

This item allows users to control non turbo CPU ratio.

CPU Frequency (100)

This item shows the information of the CPU frequency.

Enhanced Intel SpeedStep Technology (Enabled)

This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep Tech-

nology).

Turbo Mode (Enabled)

This item allows you to control the Intel Turbo Boost Technology.

Internal PLL OverVoltage (Disabled)

This item allows you to control the Internal PLL OverVoltage.

Runtime Turbo Enable (Disabled)

This item shows if CPU support runtime turbo or not.

Over Clocking Extra Vol.(1/256 V) (0)

Use this item to set over clocking extra voltage.

IA Core Current (Maximum)

Use this item to control CPU Current Limit.

iGFX Core Current (Maximum)

Use this item to control iGFX Core Current Limit.

Long Duration Power Limit Override (Maximum)

Intel(R) Turbo Boost Technology will use this power limit during the long duration

power limit time window.

Long Duration Maintained (10)

Use this item to control the time window over PL1 value should be maintained. This

is for Turbo mode.

Short Duration Power Limit Override (Maximum)

Intel(R) Turbo Boost Technology will use this power limit for a very short duration.

After that, the long duration power limit will be honored.

Graphics Voltage(1/256) (0)

This item allows you to adjust the internal GFX voltage.

Graphics Core Ratio Limit (22)

This item allows you to control the internal GFX Turbo ratio

1/2/3/4 Core Ratio Limit (34/33/33/32)

These items show the Core Ratio Limit value.

Press <Esc> to return to the M.I.B III menu page.
