Introducing the Motherboard
Specifications
• LGA1155 socket for 2
nd
Generation Intel
®
Core
TM
Family/
Pentium/Celeron processors
• Supports “Hyper-Threading” technology CPU
• DMI 5.0 GT/S
CPU
• Intel
®
H67 Chipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1333/1066
• 2 x PCI Express Gen2 x16 slots
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by Intel
®
H67 Chipset
- 4 x SATA 3.0 Gb/s Host Controllers
- 2 x SATA 6.0 Gb/s Host Controllers
• Supports RAID 0/1/5/10
• Realtek ALC892 8-Ch HD audio CODEC
• Compliant with HD audio specification
• 1 x PS/2 keyboard & PS/2 mouse combo connector
• 1 x CLR CMOS button
• 8 x USB2.0 ports (including 2 x USB ports with optional USB
3.0 specification running at 5 Gb/s)
• 1 x RJ45 LAN connector
• 1 x Audio port with 6 audio jacks (Center/Subwoofer
Speaker Out/Rear Speaker Out/Side Speaker Out/Line
in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
Giga LAN
Rear Panel I/O
• Realteck RTL8111E Gigabit Lan
• 1 x 24-pin ATX Power Supply connector, 8-pin 12V connec-
tor
• 1 x ATX4P connector
• 2 x Serial ATA 6Gb/s connectors
• 4 x Serial ATA 3Gb/s connectors
• 3 x USB2.0 headers support additional six USB 2.0 ports
(F_USB2 supports EZ Charger)
• 1 x Front panel audio header
• 1 x SPDIF out header
• 1 x Front panel header
• 1 x ME UNLOCK header
• 1 x CASE header
• 1 x Reset button
• 1 x Power button
• 1 x COM header
• CPU_FAN/SYS_FAN/PWR_FAN connectors
Internal I/O
Connectors &
Headers
• AMI BIOS with 32 Mb SPI Flash ROM
• Supports ECS M.I.B III Utility
• Supports ACPI&DMI, Plug and Play, STR(S3)/STR(S4)/S1,
Hardware monitor
System BIOS
