PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
Shutdown Temperature Disabled
Warning Temperature Disabled
CPU Temperature : 40°C/104°F
System Temperature : 36°C/96°F
CPU FAN Speed : 0
CPU Vcore : 1.344 V
VDIMM : 1.904 V
Vcc5V : 5.053 V
Help Item
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
PC Health Status
f
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 28
SMART Fan start TEMP.(°C) 27
DeltaT1 +3
SMART Fan Slope PWM value 3 PWM value/°C
CPU FAN Full Limit Temp 60°C
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Disabled
Enabled
SMART FAN Control (Enabled)
This item allows you to enable/disable the control of the system fan speed by chang-
ing the fan voltage.
