5
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
Socket for AMD Phenom
TM
II processor (socket AM3)
2. CPU_FAN
CPU cooling fan connector
3. DDR3_1~4
240-pin DDR3 SDRAM slots
4. ATX_POWER
Standard 24-pin ATX power connector
5. IDE
Primary IDE connector
6. SPK
Speaker header
7. CLR_CMOS
Clear CMOS jumper
8. SATA1~4
Serial ATA connectors
9. USBPWR_F
Front panel USB power select jumper
10. F_PANEL
Front panel switch/LED header
11. F_USB1~2
Front Panel USB headers
12. SPDIFO
SPDIF out header
13. CD_IN
Analog audio input header
14. F_AUDIO
Front panel audio header
15. PCI1~3
32-bit add-on card slots
16. PCIEX16
PCI Express x16 slot for graphics interface
17. PCIE1~2
PCI Express x1 slots
18. SYS_FAN
System cooling fan connector
19. USBPWR_R
Rear USB/PS2 power select jumper
20. ATX12V 4-pin +12V power connector
This concludes Chapter 1. The next chapter explains how to install the motherboard.
