KAM1-I USER MANUAL
44
Chapter 3
Row Precharge Time (tRP) (10)
This item specifies Row precharge to Active or Auto-Refresh of the same bank.
RAS# Active Time (tRAS) (28)
This item specifies the RAS# active time.
Read CAS# Precharge (tRTP) (6)
This item controls the Read to PRECHARGE delay for memory devices, in memory
clock cycles.
Active to Active Delay (tRRD) (5)
This item controls the ACTIVE bank x to ACTIVE bank y in memory clock cycles.
Row Refresh Cycle Time 0/1 (tRFC0/1)
This item specifies the row refresh cycle time.
Write Recovery Time (tWR) (12)
This item specifies the write recovery time.
Write to Read Delay (tWTR) (6)
This item specifies the write to read delay time.
Four Active Window Delay (tFAW) (24)
This item controls the four bank activate time in memory clock cycles.
Row Cycle Time (tRC) (37)
This item specifies the row cycle time.
