ECS NFORCE6M-A Manual&Nbsp;

5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
Socket AM2 for AMD Athlon 64 FX /Athlon 64 X2
Dual-Core/Althlon 64/Sempron processors
2.CPU_FAN
CPU cooling fan connector
3.PWR_FAN*
Power Fan connector
4.DIMM1~4
240-pin DDR2 SDRAM slots
5.ATX_POWER1
Standard 24-pin ATX power connector
6.IDE1
Primary IDE connector
7.SATA3~4*
Serial ATA connectors
8.SATA1~2
Serial ATA connectors
9.SPK1
Speaker header
10.LPT1
Onboard Parallel Port header
11.USBPWR_F
Front USB Power Select jumper
12.PANEL1
Front panel switch/LED header
13.USB2~3
Front Panel USB headers
14.TPM*
TPM Module header
15.IRDA1*
Infrared header
16.FDD1
Floppy disk drive connector
17.COM2
Onboard serial port header
18.SPDIFO1
SPDIF out header
19.CD_IN1
Analog audio input connector
20.F_AUDIO1
Front panel audio header
21.WOL1*
Wake On LAN Connector
22.PCI1~3
32-bit add-on card slots
23.PCIEX1
PCI Express x1 slot
24.CLR_CMOS
Clear CMOS jumper
25.PCIEX16
PCI Express x16 slot for graphics interface
26.W-USB*
USB Wireless Card header
27.SYS_FAN
System cooling fan connector
28.USBPWR_R
Rear USB Power Select jumper
29.ATX12V1
Standard 4-Pin ATX Power connector
1.CPU Socket
* Stands for optional components
