Using BIOS
Press <Esc> to return to the PC Health Status page.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
Press <Esc> to return to the main menu setting page.
• CPU Temperature
• CPU Fan Speed
• CPU Vcore
• VDIMM
Shutdown Temperature (Disabled)
Enable you to set the maximum temperature the system can reach before powering
down.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
SMART Fan start PWM value 28
SMART Fan start Offset (-) 30
CPU DeltaT +3
Fan1 Slope PWM value/1 Unit 5
Fan1 Full Speed Offset (-) 10
SMART Fan2 Control Disabled
Disabled
Enabled
F10: Save ESC: Exit+/-/: V
alue
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
Options
To Next Page
