Q77H2-M USER MANUAL
31
Chapter 3
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
BIOS Setup Utility
Miscellaneous
Advanced Chipset Configuration
Intel(R) Rapid Storage Technology
Integrated Peripherals
PC Health Status
Miscellaneous Configuration.
Advanced Menu
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
Miscellaneous
Scroll to this item and press <Enter> to view the following screen:
+/-/Spacebar : Change Opt.
Enter : Select
F7: Load User default Settings
:Move
F8: Save as User Default
Settings
F9: Load Default Settings
F10: Save & Exit Setup
ESC: Discard changes and Exit
Setup
AHCI Port1~6
This motherboard supports six SATA channels and each channel allows one SATA de-
vice to be installed. Use these items to configure each device on the IDE channel.
BIOS Setup Utility
AHCI Port1: Not Present
AHCI Port2: Not Present
AHCI Port3: Not Present
AHCI Port4:SONY DVD RW DRU-190S
AHCI Port5: Not Present
AHCI Port6: HDS728080PLA380
Spread Spectrum [Enabled]
Processor Multiplier 28
Bootup Num-lock [On]
USB Beep Message [Disabled]
AHCI Port1
+/-/Spacebar : Change Opt.
Enter : Select
F7: Load User default Settings
:Move
F8: Save as User Default
Settings
F9: Load Default Settings
F10: Save & Exit Setup
ESC: Discard changes and Exit
Setup
Main Advanced Power Authentication Security Boot Options Exit
Main Advanced Power Authentication Security Boot Options Exit
Version 2.15.1227. Copyright (C) 2002-2012, Inc.
Version 2.15.1227. Copyright (C) 2002-2012, Inc.
Processor Multiplier (28)
This item shows the information of the processor multiplier.
Spread Spectrum (Enabled)
Use this item to enable or disable system Spread Spectrum function, EMI (Electro-
Magnetic Interface) will reduce if this item is enabled.
