9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled.
Jumper Settings
Jumper
T
ype
Description
Setting (default)
CLR_CMOS
3-pin
CLEAR CMOS
1-2: CLEAR
2-3: NORMAL
Before clearing the
CMOS, make sure to
turn off the system.
BIOS_WP
2-pin
BIOS WRITE
OPEN: ENABLE
SHOR
T
: DISABLE
CLR_CMOS
1
BIOS_WP
1
14
16
