5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
2 DIMM1~2 240-pin DDR2 SDRAM slots
1 CPU Socket
3 ATX_POWER Standard 24-pin ATX power connector
LABEL COMPONENT
5 IDE1 Primary IDE channel
8 SATA1~4 Serial ATA connectors
4 FDD Floppy diskette drive connector
6 PWR_FAN Power fan connector
12 PANEL1 Front panel switch/LED header
7 BIOS_WP BIOS protection jumper
13 USB3-4 Front Panel USB headers
10 IRDA Infrared header
15 COM2 * Onboard serial port header
24 SYS_FAN System cooling fan connector
25 ATX12V 4-pin +12V power connector
21 PCIEX16 PCI Express x16 graphics card slot
17 CD_IN1 Analog audio input connector
18 AUDIO1 Front panel audio header
19 SPDIFO SPDIF out header
23 TV_OUT1* TV-out header
20 PCI1~2 32-bit add-on card slots
Socket AM2 for AMD Sempron/Athlon 64/
Athlon 64 X2 Dual-Core/Athlon 64 FX proces-
sors
22 PCIEX1 PCI Express x1 graphics card slot
26 CPU_FAN CPU cooling fan connector
9 WOL1 * Wake On LAN connector
11 CLR_CMOS Clear CMOS jumper
14 1394A2 * Onboard 1394a header
16 AUXIN1* Auxiliary In header
“*” Stands for optional components
