PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
SMART Fan Function [Press Enter]
Shutdown Temperature [Disabled]
Warning Temperature [Disabled]
CPU Vcore 1.45V
VDIMM 1.76V
+3.3V 3.29V
+5V 4.99V
+12V 11.84V
VBAT 3.23V
CPU Tcontrol 92°C
System Temperature 29°C
CPU FAN Speed 0 RPM
System Fan Speed 0 RPM
Item Help
Menu Level
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Smart Fan Function (Press Enter)
Phoenix-AwardBIOS CMOS Setup Utility
Smart Fan Function
Scroll to this item and press <Enter> to view the following screen:
SMART Fan Control (Disabled)
Press Ctrl + F1 to show this item. This item allows you to enable/disable the control of
the system fan speed by changing the fan voltage.
Fan1 start PWM value (0)
Press Ctrl + F1 to show this item. This item displays the PWM value smart fan starts.
Fan1 start Temp. ° C (0)
Press Ctrl + F1 to show this item which specifies the temperature value smart fan
starts.When the CPU temperature is lower than the value, the fan will function at start
PWM value.
FAN1 Limit Temp. ° C (0)
Press Ctrl + F1 to show this item. This item specifies the slope PWM value of smart fan.
Smart Fan Control [Disabled]
FAN1 START PWM VALUE 0
FAN1 START Temp 0
FAN1 Limit Temp 0
FAN1 Slope Select PWM 0
Item Help
Menu Level
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
x
x
x
x
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
To Next Page
