Using BIOS
PCIE GFX Core Payload Size (64 Bytes)
This item allows users to manually adjust the PCIE GFX Core Payload size.
PCIE GPP Core Payload Size (64 Bytes)
This item allows users to manually adjust the PCIE GPP Core Payload size.
GFX0 Link Width (x16)
This item allows users to manually set the GFX Link Width.
UMA Frame Buffer Size (32MB)
This item allows users to manually adjust the UMA frame buffer size, from 16MB to
128MB.
AGP Aperture Size (128MB)
This item allows users to manually adjust the AGP aperture size, from 32MB to 2GB.
GFX Multi Function Mode (Disabled)
This item allows users to enable or disable the GFX Multi Function Mode.
• Async GFX Clock (200MHz): This item allows users to manually adjust the
GFX clock, from 200MHz to 350MHz.
• Async GFX Clock Source (14.318MHz OSC): This item allows users to set
the GFX Clock Source, either to be 14.318MHz OSC or 100MHz PCIE.
• MCLK Spread Spectrum (Disabled): This item allows users to enable or
disable the MCLK spread spectrum function.
GFX Clock Mode (Sync)
This item allows users to set the GFX Clock Mode to be Sync or Async. When this item
is set to Sync, the following 3 item is activated.
Integrated Peripherals
These options display items that define the operation of peripheral components on
the system’s input/output ports.
Video Display Devices (Auto)
This item allows users to manually select the video display device.
Tv Standard (NTSC)
This item allows users to manually select the TV picture format.
System BIOS Cacheable (Disabled)
This feature is only valid when the system BIOS is shadowed. It enables or disables the
caching of the system BIOS ROM at F0000h-FFFFFh via the L2 cache. This greatly
speeds up accesses to the system BIOS.
Press <Esc> to return to the main BIOS setting page.
Phoenix-AwardBIOS CMOS Setup Utility
Integrated Peripherals
South OnChip IDE Device [Press Enter]
South OnChip PCI Device [Press Enter]
SuperIO Device [Press Enter]
Init Display First [PCIEx]
Surroundview Disabled
Item Help
Menu Level
x
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
To Next Page
