40
Using BIOS
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port 1/2 (3F8/IRQ4)(2F8/IRQ3)
This option is used to assign the I/O address and interrupt request (IRQ) for onboard
serial port 1/2 (COM1/2).
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Parallel Port Mode (ECP)
Enables you to set the data transfer protocol for your parallel port. There are four
options: SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Extended
Capabilities Port) and ECP+EPP.
ECP Mode Use DMA (3)
When the onboard parallel port is set to ECP mode, the parallel port can use DMA 3 or
DMA 1.
Onboard Parallel Port (378/IRQ7)
This option is used to assign the I/O address and interrupt request (IRQ) for the onboard
parallel port.
Press <Esc> to return to the main BIOS setting page.
Init Display First (PCI Slot)
Use this item to specify whether your graphics adapter is installed in one of the PCI
slots or is integrated on the motherboard. If a PCI graphics card is installed, the
onboard VGA will be disabled.
Surroundview (Disabled)
This item allows you to enable or disable Surroundview function. Surroundview
TM
provides the power and convenience of multiadapter, multimonitor support for
computers that use an AGP or PCI-E based graphics card in conjunction with ATI
integrated graphics processors.
Onboard FDC Controller [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [ECP]
ECP Mode Use DMA [3]
SuperIO Device (Press Enter)
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
SuperIO Device
Scroll to this item and press <Enter> to view the following screen:
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
To Next Page
