3
Introducing the Motherboard
Onboard LAN (Optional)
This motherboard may support either of the following LAN chipset:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
Some hardware specifications and software items are subject to change
without prior notice.
BIOS Firmware
This motherboard uses AWARD BIOS that enables users to configure many system
features including the following:
The firmware can also be used to set parameters for different processor clock speeds.
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• One VGA port
• Four USB ports
• One 1394 port (optional)
• One LAN port (optional)
• Audio jacks for microphone, line-in and line-out
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
This motherboard supports UltraDMA bus mastering with transfer rates of 133/100/66/
33 MB/s.
The motherboard comes with the following expansion options:
Expansion Options
• One PCI Express x16 for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One 40-pin IDE connector supporting up to 2 IDE devices
• One floppy disk drive interface
• Four 7-pin SATA connectors
• Supports 10/100 Mb/s N-Way Auto negotiation operation
• Half/Full duplex capability
• Supports Wake-On-LAN (WOL) function and remote wake-up
• Integrate 10/100/1000 transceiver
• Supports PCI v2.3, 32-bit, 33/66 MHz
• Supports fully with IEEE802.3, IEEE802.3u and IEEE802.3ab
1394a FireWire (Optional)
• Fully compliant with provisions of IEEE Std 1394-1995 for a high-perfor-
mance serial bus and IEEE Std 1394a-2000
• Two IEEE Std 1394a-2000 fully compliant cable ports at 400 Mbit/s
