12
Installing the Motherboard
Installing Memory Modules
This motherboard accommodates four memory modules. It can support six 240-pin
DDR3 1333/1066/800. The total memory capacity is 24 GB.
You must install at least one module in any of the six slots. Each module can be
installed with 4 GB of memory; total memory capacity is 24 GB.
DDR3 SDRAM memory module table
Memory module Memory Bus
DDR3 800 400 MHz
DDR3 1066 533 MHz
DDR3 1333 667 MHz
ff
Channel A: DDR3_1, DDR3_2
ff
Channel B: DDR3_3, DDR3_4
The six DDR3 memory sockets (DDR3_1, DDR3_2, DDR3_3, DDR3_4, DDR3_5,
DDR3_6) are divided into three channels and each channel has two memory sockets
as following:
ff
Channel C: DDR3_5, DDR3_6
1. To achieve better airflow rates and heat dissipation, we suggest that
you use a high quality fan with 3800 rpm at least. CPU fan and
heatsink installation procedures may vary with the type of CPU fan/
heatsink supplied. The form and size of fan/heatsink may also vary.
2. DO NOT remove the CPU cap from the socket before installing a
CPU.
3. Return Material Authorization (RMA) requests will be accepted
only if the motherboard comes with the cap on the LGA1366 socket.
Due to Intel CPU spec definition, the system will not boot if only one
DIMM is installed in DDR3_1, DDR3_3, or DDR3_5. Follow the table
above for recommended memory configuration.
DDR3_1 DDR3_2 DDR3_3 DDR3_4 DDR3_5 DDR3_6
2 DIMMs - Populated - Populated - -
3 DIMMs - Populated - Populated - Populated
4 DIMMs Populated Populated - Populated - Populated
6 DIMMs Populated Populated Populated Populated Populated Populated
Mode
Sockets
Recommend memory configuration
