Using BIOS
M.I.B (MB Intelligent BIOS)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2005 American Megatrends, Inc.
M.I.B (MB Intelligent BIOS)
Help Item
Options
Enabled
Disabled
Manufacturer : Intel
Ratio Status : Unlocked (Min:12, Max:20)
Ratio Actual Value : 20
BCLK Speed : 133MHz
Performance Level Standard
CPU Over-clocking Func. : Disabled
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
CPU Current Voltage 1.21250V
CPU Voltage Disabled
NB Vcore 1.120 V
IOH Voltage Disabled
CPU VTT 1.184 V
CPU VTT Voltage Disabled
VDIMM 1.456 V
DIMM Voltage Disabled
SB Vcore 1.232 V
SB Voltage Disabled
Current Memory Frequency 1066 Mhz
DRAM Frequency Auto
Configure DRAM Timing by SPD Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
*
Manufacturer (Intel)
This item displays the information of current manufacturer of the CPU installed
in your computer.
Ratio Status/Ratio Actual Value
These items show the Locked ratio status and the actual ratio of the CPU installed
in your system.
BCLK Speed (133MHz)
This item shows the speed of BCLK.
Performance Level (Standard)
If the item is set to Standard, the system will run at its basic performance level. If
the item is set to Enhanced, the system will run at its good performance level and
enable overclocking function.
CPU Over-clocking Func. (Disabled)
This item decides the CPU over-clocking function installed in your system.
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Spread Spectrum (Enabled)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
