38
Using BIOS
Press <Esc> to return to the main menu setting page.
CPU Current Voltage (1.21250V)
This item allows users to adjust the CPU current voltage.
CPU Voltage (Disabled)
This item allows users to adjust the CPU voltage.
NB Vcore (1.120 V)
This item shows the Northbridge Vcore.
IOH Voltage (Disabled)
This item allows users to adjust the IOH voltage.
CPU VTT (1.184 V)
This item shows the CPU VTT.
CPU VTT Voltage (Disabled)
This item allows users to adjust the CPU VTT voltage.
VDIMM (1.456 V)
This item shows the VDIMM.
DIMM Voltage (Disabled)
This item allows users to adjust the DIMM voltage.
Warning: Since the manual adjustment to the DIMM setting may result
in the instability of the system, users need adjust it carefully when over-
clocking.
SB Vcore (1.232 V)
This item shows the Southbridge Vcore.
SB Voltage (Disabled)
This item allows users to adjust the Southbridge voltage.
Current Memory Frequency (1066 MHz)
This item shows the current memory frequency.
DRAM Frequency (Auto)
This item allows users to adjust the DRAM frequency.
Configure DRAM Timing by SPD (Enabled)
When this item is set to enable, the DDR timing is configured using SPD. SPD (Serial
Presence Detect) is located on the memory modules, BIOS reads information coded
in SPD during system boot up.
