EDAN SD3 Series User Manual

SD3 Series Ultrasonic Pocket Doppler User Manual Doppler and Accessories
- 11 -
Real-time Test Record Play
Charge Error Real-time Test
Figure 2-6 OLED Display
When 4/5/8 MHz vascular probe is plugged in, the OLED displays the probe type instead of the
FHR.
No.
Symbol
Description
1
HR being calculated
2
Full capacity
3/4 capacity
2/4 capacity
1/4 capacity
Empty, the flickering interface prompts replacement or
charging of battery.
3
HR: 50-240
4
SD3 PRO: in playing status
5
SD3 PRO: in recording status
6
The machine is not connected to the probe.
7
Probe frequency
8
Charge interface:
Electric energy pane refreshed from negative polarity
to positive polarity
charge completed
