SD3 Series Ultrasonic Pocket Doppler User Manual Basic Operation
- 20 -
Figure 3-1 On a Table Figure 3-2 On the Wall
NOTE:
The Doppler is not available for examining during charging.
WARNING
1 The charge stand can be fixed only on a concrete wall.
2 When you need to install the charge stand a second time, drill new holes and
change the screws.
3 The charger and the power adapter meet the requirements of Standard IEC60950,
and they should be placed outside the patient environment when they are working
(1.5 m away from the patient).
