EDAN SD3 Series User Manual

SD3 Series Ultrasonic Pocket Doppler User Manual Examining
- 25 -
Figure 4-1 Probe sites
For best results, keep the probe as still as possible once the optimum position is found. Adjust the
volume as required. High pitched pulsatile sounds are emitted from arteries while veins emit a
non-pulsatile sound similar to a rushing wind.
Vascular examination only provides audio signals of arteries and veins. The OLED screen always
displays the probe frequency.
Vertebral Artery (4.0MHz)
Carotid Artery (4.0/8.0MHz)
Carotid Artery (4.0/8.0MHz)
Subclavian Artery (4.0MHz)
Subclavian Vein (4.0MHz)
Jugular Vein (4.0MHz)
Brachial Artery (8.0MHz)
Ulner Artery (8.0MHz)
Radial Artery (8.0MHz)
Femoral Artery (4.0MHz)
Hz)
Popliteal Artery (4.0MHz)
Great Saphenous Vein (4.0/8.0MHz)
Small Saphenous Vein (8.0MHz)
Posterior Tibial Artery (8.0MHz)
(8.0MHz)
Vertebral Artery (4/5 MHz)
Carotid Artery (4/5/8 MHz)
Carotid Artery (4/5/8 MHz)
Subclavian Artery (4/5 MHz)
Subclavian Vein (4/5 MHz)
Jugular Vein (4/5 MHz)
Brachial Artery
(8 MHz)
Ulnar Artery
(8 MHz)
Radial Artery (8 MHz)
Femoral Artery
(4/5 MHz)
Femoral Vein
(4/5 MHz)
Popliteal Artery (4/5 MHz)
Great Saphenous Vein
(4/5/8 MHz)
Small Saphenous Vein
(8 MHz)
Posterior Tibial Artery (8 MHz)
Dorsalis Pedis Artery
(8 MHz)
Posterior Tibial Vein
(8 MHz)
