SONOTRAX(2009) Series Ultrasonic Pocket Doppler User Manual
31
CAUTION
1 If the Doppler is not used for an extended
period, take the alkaline/NI-MH batteries out
and store them in a cool and dry environment.
2 Do not remove the NI-MH battery pack
frequently after initial installation.
3 If the Doppler is not used for an extended
period, charge the NI-MH batteries or the
NI-MH battery pack at least every three
months.
3.3 Probe Operation
(1) Taking out the probe
Hold the main unit with one hand. Pinch the probe
and pull it outwards using mild force.
理邦保密文件
EDAN CONFIDENTIAL

EDAN SONOTRAX Lite Specifications

General

Type	Fetal Doppler
FHR Accuracy	± 1 bpm
Display	LCD
Audio Output	Built-in Speaker and Headphone Jack
Application	Fetal Heart Rate Detection
Probe Frequency	2 MHz
Ultrasound Frequency	2 MHz
Battery	2 x AA batteries
Power Supply	2 x AA batteries
Doppler Modes	Continuous Wave
FHR Range	50-210 bpm
