PRODUCT SPECIFICATIONS:
Operating Ranges:
Range Resolution Accuracy
0 – 2 mA 1 µA 1%
0 – 20 mA 0.01 mA 1%
Input Ratings:
Voltage Amperes Frequency
100 – 120 VAC 15 A 50 / 60 Hz
200 – 240 VAC 15 A 50 / 60 Hz
Body Circuit Impedance:
2000 Ω ±20 Ω
Output Ratings: Same as Input ratings
Testing Tolerance: 90-132 / 180-264 VAC
Display: 3-1/2 Digit LCD display
Power Connection: Certified power supply cord with integral plug
Environmental Ratings: Operating Temperature: 0°C to 50°C.
Storage Temperature: –40°C to 70°C.
Humidity: 80% R.H., 0°C to 35°C
Overall Dimensions:
11-1/2 in. W x 13-1/2 in. D x 5-1/4 H in. (29.2 cm
W x 34.3 cm D x 13.33 cm H) Overall Weight: 9.0
lb. (4.0 Kg)
Body Circuit: Precision network in accordance with UL 2950 /
CSA 950 (bi-national standard), IEC 950 and
EN60950
Measurement Method: True RMS Responding Meter
Meter Measurement Reference:
Neutral @ 115 VAC
Ground @ 230 VAC
Meter Connection Selector Switch: Allows the meter measurement point to be selected
as either:
Through product’s power cord grounding
conductor
From an exposed surface to the meter
reference point
Between two exposed surfaces
Frequency Response of the Meter: The LT-952 measures cumulative leakage current
from all frequencies up to and including 1MHz.
