PRODUCT COMPONENTS:
I. Figure 1 - Front Panel
A. Neutral Open / Closed Switch
B. Line Forward / Reverse Switch
C. Ground Open / Closed Switch
D. LCD Display
E. Power On / Off Switch
F. D.U.T. (Device Under Test) Receptacle
G. Open / Closed Ground Indicator Lights
H. Meter Connection Jacks
I. Range Selector Switch
J. Meter Reference Switch
K. Meter Connection Switch
L.
A
B C D
E F G
I
H
J
K
