PARTS LISTING - ILLUSTRATION 9:
MOTOR & BELT DRIVE GROUPING FOR 1.5 HP UNITS
ITEM # PART # DESCRIPTION QTY.
1 76027
77039
16101
76002
16070
16524
16161
16534
MOTOR, BALDOR 1.5HP-1P-60HZ-115/230V-1725RPM
BALDOR SPEC. 36F57-385 (7/8” SHAFT)
REPLACEMENT PARTS:
CAPACITOR, START, BALDOR, 850-950MFD 115V
RESET BUTTON, BALDOR TPCRT31CA
SWITCH, TOGGLE DPDT (SCREW TERM.)
MOTOR, LEESON 1.5HP-1P-60HZ-115/230V-1740RPM
LEESON CAT. NO. 132189 (1-1/8” SHAFT)
REPLACEMENT PARTS:
CAPACITOR, START, LEESON, 1190MFD 125V
RESET BUTTON, LEESON BRJ44DB
SWITCH, TOGGLE DPDT (PUSH-ON TERM.)
1
1
1
1
1
1
1
1
2 77043 SWITCH, ROTARY CAM ON/OFF, LOVATO 1
3 77042 BRACKET, LOVATO ROTARY CAM SWITCH 1
4 11663 SCREW, MACHINE 8-32 X 1/2
(LOCATED INSIDE OF SWITCH BOX)
4
5 10462 NUT, KEPS LOCK 8-32 ZINC 4
6 11690 CLAMP, LOOM, 3/8” 1
7 10038 WASHER, LOCK 1/4 ZINC 2
8 10846 SCREW, CAP STSHW 1/4-20 X 1/2 2
9 77043-1 SWITCH ADAPTER, PG16 TO 1/2”NPT 2
10 40066 STRAIN RELIEF 1/2NPT X .350-.450” 2
11 16176 STRAIN RELIEF 3/4NPT X .350-.450” 1
12 77044 PLUG W/ 12/3 WIRE HARNESS, LOCKING 1
13 40041 CONNECTOR, LOCKING 20A/125V L5-20C 1
14 77045 WIRE HARNESS 12/3 X 42”LOA 1
15 10982 TIE, CABLE, BLACK NYLON 11-1/4” 2
16 77037 MOUNT, MOTOR 1
17 10021 SCREW, CAP 3/8-24 X 1 4
18 10025 WASHER, FLAT 3/8 SAE ZINC 8
19 10811 WASHER, LOCK 3/8 ZINC 4
20 10014 NUT, HEX 3/8-24 ZINC 4
21 10802 BOLT, CARRIAGE 3/8-16 X 1 FULL THD. 4
22 10404 NUT, HEX 3/8-16 ZINC 4
23 77017
77030
SHEAVE 3”OD X 1GR.B X 7/8”BORE (BALDOR 1.5HP)
SHEAVE 3”OD X 1GR.B X 1-1/8”BORE (LEESON 1.5HP)
1
1
24 ----- KEY (INCLUDED W/ MOTOR) 1
25 10051 BELT 5L-270 (21/32” X 27”) 1
26
3654 SHEAVE 5”OD X 1GR.B X 3/4”BORE 1
27 10016 KEY 3/16SQ X 1-1/2 1
28 15204 PLUG, RECT. HOLE, PLASTIC SNAP-IN 1
