Page 19
PARTS LISTING - ILLUSTRATION 11:
ENGINE & BELT DRIVE GROUPING FOR HONDA GX160
ITEM # PART # DESCRIPTION QTY.
1 76020 ENGINE, HONDA GXV160UH2-N12
WITH STANDARD DUAL ELEMENT AIR CLEANER
1
2 15180 MANUAL CHOKE KIT FOR HONDA GXV160
(INCLUDES ITEMS 3 THRU 9)
1
3 15182 BRKT., CHOKE CONTROL, GXV160 1
4 15181 LEVER, CHOKE CONTROL, GXV160 1
5 15184 CAP, FLAT RED .062 X .75 X 1 1
6 91301 DECAL, CHOKE 5/8 X 5/8 1
7 10834 SCREW, CAP 1/4-20 X 1/2 1
8 15186 WASHER, BELLEVILE .500 X.255 X.018 1
9 10150 NUT, HEX NYLON LOCK 1/4-20 1
10 11541 BARB, PUSH-ON 3/8 HOSE X10MM X 1.25 1
11 72106 HOSE, PUSH-ON 3/8”ID X 2-1/4”L 1
12 11544 BARB, PUSH-ON 3/8 HOSE X 1/4FPT 1
13 10776 PIPE PLUG 1/4 NPT (BRASS) 1
14 40388 CABLE, THROTTLE, LEVER-TYPE 24” 1
15 10877 SCREW, CAP STSHW 10-24 X 1/2 2
16 10831 WASHER, LOCK, INT. TOOTH #10 2
17 10982 TIE, CABLE, BLACK NYLON 11-1/4” 1
18 15201A
50084
10831
10877
10970
36042
SWITCH W/ WIRES, ROCKER RED ON-OFF
ADDITIONAL PARTS REQ’D. (NOT SHOWN);
TERM., RING #10 16-14GA. INSULATED
WASHER, LOCK, INT. TOOTH #10
SCREW, CAP STSHW 10-24 X 1/2
CONN., WIRE QUICK-SPLICE 18-14 GA.
CLIP, NATURAL CORD, 1/8” X 1/4”
1
1
1
1
1
2
19 76023 MOUNT, ENGINE, VERT. SHAFT 1
20 10048 SCREW, CAP 5/16-24 X 3/4 2
21 10801 WASHER, LOCK 5/16 ZINC 4
22 10342 SCREW, CAP 5/16-18 X 1-1/2 2
23 10213 WASHER, FLAT 5/16 SAE ZINC 2
24 10054 NUT, HEX 5/16-18 ZINC 2
25 10802 BOLT, CARRIAGE 3/8-16 X 1 FULL THD. 4
26 10025 WASHER, FLAT 3/8 SAE ZINC 4
27 10811 WASHER, LOCK 3/8 ZINC 4
28 10404 NUT, HEX 3/8-16 ZINC 4
29
10019 KEY, WOODRUFF 5/32 X 5/8 (#505) 1
30 77024 CLUTCH, CENTRIFUGAL 3.5 X 1GR X 7/8 1
31 72006 WASHER, 1-1/4OD X 13/32ID X 1/8THK 1
32 10811 WASHER, LOCK 3/8 ZINC 1
33 10336 SCREW, CAP 3/8-24 X 2-1/4 1
34 10051 BELT 5L-270 (21/32” X 27”) 1
35 3654 SHEAVE 5”OD X 1GR.B X 3/4”BORE 1
36 10016 KEY 3/16SQ X 1-1/2 1
I 3 •Ii•J
