PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING
ITEM # PART # DESCRIPTION QTY.
1 77022 MAIN FRAME & GEAR CASE, 2-EC/GC 1
2 77007 COVER, GEAR CASE, 2-EC/GC 1
3 10005 PLUG, HOLE 7/8” BRIGHT ZINC 1
4 10602 WASHER, FLAT 1/4 SAE ZINC 10
5 10038 WASHER, LOCK 1/4 ZINC 10
6 10018 SCREW, CAP 1/4-20 X 3/4 10
7 77008 BEARING, BALL 1” 4-HOLE FLANGE, ND 4
8 10450 WASHER, LOCK 7/16 ZINC 16
9 10481 NUT, HEX 7/16-20 ZINC 16
10 77009 BEARING, BALL 3/4” 4-HOLE FLANGE 2
11 10309 SCREW, CAP 3/8-24 X 1-1/4 ZINC 4
12 10811 WASHER, LOCK 3/8 ZINC 8
13 10014 NUT, HEX 3/8-24 ZINC 8
14 77013 SHAFT, LARGE GEAR 1”DIA X 7-13/16”L 2
15 77012 GEAR, SPUR 112 TOOTH (DRIVEN) 2
16 10007 PIN, ROLL 3/8 X 2-1/2 2
17 77011 SHAFT, PINION GEAR 3/4DIA X 7-3/8”L 1
18 10037 PIN, ROLL 1/4 X 1-1/2 1
19 77053 GEAR, SPUR 25 TOOTH (PINION) 1
20 10009 WASHER, FLAT 3/4 SAE ZINC 1
21 9999 DISC ASSY. COMPLETE, MULTI-ACCY. LH (SEE ILLUS. 3) 1
22 8888 DISC ASSY. COMPLETE, MULTI-ACCY. RH (SEE ILLUS. 3) 1
23 10063 PIN, ROLL 3/8 X 2 2
24 77215 AXLE SPACER 9-5/8”L, 2-EC/GC 1
25 77209 AXLE SHAFT 3/4”DIA. X 17”L, 2-EC/GC 1
26 79013SH WHEEL, STL.HUB 8 X 2-1/2 X 3/4”BRG. 2
27 77214 SPACER, WHEEL 3/8”L, 2-EC/GC 2
28 11597 WASHER .755”ID X 1.25”OD X .060”THK (*USE AS REQ’D.) 2*
29 86305 FLIP-HOLDER, WHEEL AXLE 2
30 10139 SCREW, SET 1/4-20 X 5/16 2
31 10321 SCREW, CAP 1/2-20 X 1-1/4 2
32 10312 WASHER, FLAT 1/2 SAE ZINC 2
33 10205 NUT, HEX LOCK 1/2-20 ZINC 2
34 74010 HANDLE BAR, 2-EC/GC 1
35 10608 GRIP, HAND 1” MODEL AT 2
36 10029 SCREW, CAP 3/8-24 X 1-3/4 4
37 10025 WASHER, FLAT 3/8 SAE ZINC 8
38 10004 NUT, HEX LOCK 3/8-24 ZINC 8
39 77077 HOOD, GRINDER, 2-EC/GC 1
40 10860 BOLT, TAP 1/4-20 X 1-1/4 (FULL THD) 2
41 10013 NUT, HEX 1/4-20 ZINC 2
42 10602 WASHER, FLAT 1/4 SAE ZINC 2
43 10861 NUT, KEPS LOCK 1/4-20 ZINC 2
