PARTS LISTING - ILLUSTRATION 2:
SKIRT, VACUUM PORT & WATER HOOK-UP GROUPING
ITEM # PART # DESCRIPTION QTY.
1 77001 SKIRT GUARD, 2-EC/GC 1
2 10806 SCREW, CAP 5/16-18 X 1 5
3 10801 WASHER, LOCK 5/16 ZINC 5
4 10213 WASHER, FLAT 5/16 SAE ZINC 5
5 77112 PANEL, VACUUM PORT 2”, 2-EC/GC 1
6 10113 SPACER, STEEL 9/16OD X 3/8ID X 7/32 2
7 77141 RUBBER SEAL, SKIRT, 2-EC/GC
2-1/2 x 56
1
8 77142 RUBBER SEAL, SKIRT REAR, 2-EC/GC
2-1/2 x 16
1
9 77143 RETAINING STRIP, RUBBER SEAL, 2-EC/GC 1
10 77339 RETAINING BRKT., SKIRT CORNER 2
11 77144 RETAINING STRIP, REAR SEAL, 2-EC/GC 2
12 11676 BOLT, CARRIAGE 1/4-20 X 5/8 GRADE 2 13
13 10602 WASHER, FLAT 1/4 SAE ZINC 13
14 10861 NUT, KEPS LOCK 1/4-20 ZINC 13
15 86347 BRACKET, MULTI-VAC PORT 2-3” 1
16 65021 CAP/PLUG 2” RED PLASTIC, FLANGED 1
17 10846 SCREW, CAP STSHW 1/4-20 X 1/2 4
18 10038 WASHER, LOCK 1/4 ZINC 4
19 77113 HOSE, FLEX 2”ID X 32”L, GRINDERS 1
20 10766 CLAMP, HOSE, SAE #32, ADJ. TO 2-1/2 2
21 56022 BRACKET, WATER VALVE 1
22 10711 VALVE, BALL 1/2 FPT 1
23 80021 CONN., SWIVEL FEM. 3/4HOSE X 1/2MPT 1
24 10799 BARB ELBOW 90, 3/8HOSE X 1/4MPT 1
25 65081 HOSE, WATER 3/8”ID X 34”L 1
26 50069 CLAMP, HOSE, SAE #6, ADJ. TO 13/16 2
27 10982 TIE, CABLE, BLACK NYLON 11-1/4” 2
28 10694 BARB, 3/8HOSE X 1/8MPT 1
29 10772 ELBOW, STREET 1/8NPT X 45 (BRASS) 2
