HD-KL14-0124
Page 17
PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING
ITEM # PART # DESCRIPTION QTY.
1 54001HD MAIN FRAME, KL-14 1
2 54010 AXLE SHAFT, 3/4DIA. X 19, KL14 1
3 10009 WASHER, FLAT 3/4 SAE ZINC 6
4 79013 WHEEL, 8 X 2-1/2 X 3/4”BRG.POLY HUB 2
5 11597 WASHER .755”ID X 1.25”OD X .060”THK 4
6 10306 PIN, COTTER 3/16 X 1-1/2 4
7 54006HD FORK, KL-14 1
8 54031 FORK WHEEL SPACER, KL14 2
9 54026 WHEEL, 4 X 2 X 3/4 W/ ROLLER BRG. 2
10 54005HD CUT CONTROL, LINKAGE WELDMENT KL14 1
11 10202 SCREW, CAP 1/2-20 X 3 1
12 10205 NUT, HEX LOCK 1/2-20 ZINC 1
13 54002HD LOWER HANDLE, KL-14 1
14 10021 SCREW, CAP 3/8-24 X 1 2
15 10025 WASHER, FLAT 3/8 SAE ZINC 4
16 10058 NUT, HEX LOCK 3/8-24 W/ NYLON PATCH 2
17 11851 SCREW, SKT. HD. CAP 3/8-24 X 3/4 SS 4
18 10152 NUT, HEX NYLON LOCK 3/8-24 ZINC 4
19 80008 HANDWHEEL, SMALL W/ 5/8-11 X 12”ROD 1
20 14023 KNOB, BALL 1-3/8 W/ 1/2-13THD, BLK. 1
21 50550 SLEEVE, BRASS 1/2” TAPERED 1
22 10411 SCREW, SKT. HD. CAP 1/2-13 X 4 ZINC 1
23 80009 BEARING, BALL 5/8” 2-HOLE (NO G.F.) 1
24 55010 SPACER, HANDWHEEL 5/8”ID X 3/4”L 1
25 10046 NUT, HEX 5/8-11 ZINC 1
26 10412 BOLT, CARRIAGE 1/4-20 X 1 2
27 10602 WASHER, FLAT 1/4 SAE ZINC 2
28 10861 NUT, KEPS LOCK 1/4-20 ZINC 2
29 54003HD UPPER HANDLE, KL-14 1
30 10608 GRIP, HAND 1” MODEL AT 2
31 10087 BOLT, CARRIAGE 3/8-16 X 1-3/4 2
32 28133 WASHER, FLAT 13/32 X 1-1/4 X .047 2
33 10025 WASHER, FLAT 3/8 SAE ZINC 4
34 56018 BUSHING, RUBBER 1”OD X 3/8”ID X 1/4 2
35 80011 KNOB, 3-PRONG W/ 3/8-16 THD. 2
36 54008HD GUIDE BAR, KL-14 1
37 10885 SCREW, CAP 3/8-24 X 3 1
38 10025 WASHER, FLAT 3/8 SAE ZINC 4
39 50024 WHEEL 4 X 1-3/8 X 3/8”BORE 1
40 10011 SPACER, STEEL 5/8OD X 3/8ID X 3/8T 1
41 10058 NUT, HEX LOCK 3/8-24 W/ NYLON PATCH 3
42 10021 SCREW, CAP 3/8-24 X 1 1
