HD-KL14-0124
Page 19
PARTS LISTING - ILLUSTRATION 2: ARBOR & BLADE GUARD GROUPING
ITEM # PART # DESCRIPTION QTY.
1 54011A ARBOR ASSY. COMPLETE, KL-14 (ITEMS 2 -10) 1
2 54011 ARBOR SHAFT, KL-14 1
3 10211 PIN, ROLL 5/16 X 2 1
4 56026 ARBOR BACKING PLATE 4” 1
5 56025 ARBOR BLADE CAP 4”OD W/1”HOLE 1
6 55009 WASHER, LOCK, INT. TOOTH 1” 1
7 50019 NUT, HEX JAM 1-14 ZINC GRADE A 1
8 50222 BEARING, BALL 1” TPB
NOTE: COLLARS FACE INWARD
2
9 40317 KEY 1/4SQ X 1-5/8 1
10 52125 SHEAVE 2.75”OD X 2GR.3V X 1”BORE 1
11 10907 SCREW, CAP 3/8-16 X 3/4 4
12 10811 WASHER, LOCK 3/8 ZINC 4
13 54024 WRENCH, KL-14 2
14 54034HD GUARD, BLADE 14”, KL-14 1
15 54025 FLAP, SPLASH 2-1/2 X 5 1
16 11811 BOLT, FLANGE 1/4-20 X 3/4 ZINC 1
17 10602 WASHER, FLAT 1/4 SAE ZINC 1
18 10150 NUT, HEX NYLON LOCK 1/4-20 ZINC 1
19 10386 SCREW, CAP 1/2-13 X 4-1/2 1
20 10045 WASHER, LOCK 1/2 ZINC 1
21 10040 WASHER, GARRET 17/32 X 1 X .054 1
22 10055 SCREW, CAP 3/8-16 X 1 1
23 10811 WASHER, LOCK 3/8 ZINC 1
24 10025 WASHER, FLAT 3/8 SAE ZINC 1
25 99323 BARBED FITTING, “Y” 1/4”HOSE 1
26 54015 HOSE, WATER 1/4”ID X 4.75”, KL-14 2
27 54016 HOSE, WATER 1/4”ID X 14”, KL-14 1
28 10711A VALVE & HOSE CONNECTOR ASSY. 1
29 54017HD BRACKET, WATER VALVE, KL-14 1
30 97034 BARB, 1/4HOSE X 1/4MPT (BRASS) 1
31 11744 CLAMP, HOSE, SPRING-BAND 3/8” BLK 1
32 11811 BOLT, FLANGE 1/4-20 X 3/4 ZINC 2
33 10861 NUT, KEPS LOCK 1/4-20 ZINC 2
34* HG1412V3 DIAM.BLADE 14” X .125” X 1” 1*
*NOTE: THE DIAMOND BLADE IS NOT INCLUDED WITH THE SAW.
