HD-KL14-0124
Page 21
PARTS LISTING - ILLUSTRATION 3: ENGINE & BELT DRIVE GROUPING
ITEM # PART # DESCRIPTION QTY.
1 15054 ENGINE, HONDA GX200UT2QX2 1
2 15303 MUFFLER CAP, HONDA #18331-883-810 1
3 11872 SCREW, MACHINE M4-0.7 X 6MM PHP 2
4 10817
10918
BOLT, CARRIAGE 5/16-18 X 1-1/2
BOLT, CARRIAGE 5/16-18 X 1-3/4
3
1
5 10213 WASHER, FLAT 5/16 SAE ZINC 4
6 10801 WASHER, LOCK 5/16 ZINC 4
7 10054 NUT, HEX 5/16-18 ZINC 5
8 52015 BOLT, TAP 3/8-16 X 3-1/2(FULL THD.) 1
9 10404 NUT, HEX 3/8-16 ZINC 1
10 52125 SHEAVE 2.75”OD X 2GR.3V X 1”BORE 1
11 40317 KEY 1/4SQ X 1-5/8 1
12 40694 SHEAVE 2.75”OD X 2GR.3V X 3/4”BORE 1
13 10170 KEY 3/16SQ X 1-3/4 (INCLUDED WITH ENGINE) 1
14 36921 BELT 3VX-250 COG 2
15 54009HD BELT GUARD, KL-14 1
16 11811 BOLT, FLANGE 1/4-20 X 3/4 ZINC 2
17 54028 OIL DRAIN KIT, KL14-6.5H HONDA 1
18 11565 CLAMP, LOOM, 5/8” (SAE SIZE 10) 1
19 10846 SCREW, CAP STSHW 1/4-20 X 5/8 1
20 10038 WASHER, LOCK 1/4 ZINC 1
21 54019H LEVER CONTROL, THROTTLE, KL14-6.5H 1
22 10830 SCREW, MACHINE PPH 10-32 X 1/2 2
23 10832 NUT, KEPS LOCK 10-32 ZINC 2
24 15201A SWITCH W/ WIRES, ROCKER RED ON-OFF 1
25 36042 ADHESIVE CORD CLIP 5/8”SQ. 5
26 10968 TERM., RING 5/16 16-14GA. INSULATED 1
27 10452 WASHER, LOCK, INT. TOOTH 5/16” 1
28 10970 CONN., WIRE QUICK-SPLICE 18-14 GA. 1
To Next Page
