edding in-line 12 - Speed Charts; Print Speed and Settings

Page 27
5 Speed charts
5.1 Print speed and settings
The following table shows which settings and which encoder are required to reach the desired
print speed for a clean print image:
Print speed in m/min
Max. horizontal
resolution in dpi
Max. vertical
resolution in dpi
Number of encoder
pulses in ppr (with
63.7mm diameter)
20
600
600
5000
30
600
600
5000
40
400
600
5000
60
300
600
5000
80
200
600
2500
100
150
600
2500
120
150
600
2000
140
100
600
1200
160
100
600
1200
180
100
600
800
Note for machine integrators:
The maximum input frequency of the encoder connector is 25kHz.
