Edge 540 - Main Landing Gear Attachment

EDGE 540. Instruction Manual
8
 2) Follow diagram below for wheel pant
installation:
1) The blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount
the main landing gear to the fuselage.
INSTALLING THE MAIN LANDING GEAR.
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
Repeat the process for the other wheel.
wheel collar.
wheel.
Lite-Plywood
block.
Axle.
Washer.
M3.
M3.
wheel Pant.
wheel.
M3.
M3.
wheel collar.
Lite-Plywood
block.
nut.
Axle.
Washer.
Landing Gear.
4x20mm.
14mm.
7mm.
wheel Pant.
Locker glue.
Locker glue.
