1 Remove the keys from the ignition and disconnect both batteries. Failure to do
so may cause damage to the PCM and Revolver.
2 Remove the driver’s side kick panel.
3 Remove the emergency brake bracket by removing the (3) 13mm nuts from the
braket and lay the entire assembly on the oor.
Required Tools
- 13mm Socket
- Screw driver
4
REVOLVER INSTALLATION 1995-1997 Trucks
