Edge REVOLVER - Cleaning Terminal Contacts

5 Remove the PCM from the plastic housing and remove the plastic cap exposing
the terminal.
6 With the provided Scotch-Brite pad clean the rubberized protective coating off
of the terminal contacts. Both sides of the terminal need to be cleaned. It is
important that the contacts are sufciently clean to avoid any connection issues.
CAUTION: Be careful when cleaning the connector to not damage the contacts
with excessive force.
NOTE: For better access to clean the terminal contacts. The (6) 5.5mm bolts can be
removed and the PCM split open. This needs to be done in a clean enviroment.
7 Use the Alcohol Prep pad to wipe away any debris on the terminal contacts.
