Edge10 C171 - 5 Product Specification; 6 Display Modes

13
Product Specification
Model
Spec
PC
LCD Display 17 " active matrix TFT LCD panel
Pixel pitch 0.264(H)x0.264(V) mm
Max Resolution 1280(H)x1024(V)SXGA
Dimensions 198(D)x397H)x374(W) mm
Packing
Dimensions
145(D)x460(H)x418(W) mm
Contrast Ratio 450:1
Brightness 300cd/m2
Response Time 5ms
Display Colour 16.7M
Viewing Angle L/R
+75°~-75°
U/D
+70°~-60 °
PC Interface Video
Sync
RGB analog 0.7Vp p
Display Mode VGA/SVGA/XGA/SXGA
PC connector 15 pin D-sub
Front Control Power on/off with LED, Menu select, Up/Down
Adjustment, Source Tuning
OSD Adjustment Contrast, Brightness, Auto Size, Phase,
Position, Input selection, Audio control
Audio speaker 2W
Power input AC Input:100~240V/1.2A,50-60Hz
Operating
Consumption
42W
Operating
Conditions
Temperature:0℃-40 Humidity: 20%℃ -80%
Storage Conditions Temperature:-10℃-60 Humidity: 20%℃ -80%
Glass Optic toughened glass 8h
Certification FCC(DOC), CE, TUV
Weight N/W: 4.4kgs G/W: 5.5kgs
