4.0 Installation
Terminal Connection
f
e
d
c
NO. Terminal Function
c
AC-In AC power input 100~240V, 50/60HZ
d
Audio-In (optional) Audio input
e
DVI-In (optional) To PC DVI
f
D Sub 15 VGA -In
To PC
D Sub 15 VGA
Pre-installation Check
Please check the label on the nameplate on the back cover first. Input voltage between 100V and 240V should be
used with this monitor. Also please make sure this monitor and your main system (computer) is powered off before
attaching any connectors.
