3
Window Kit Parts List:
Window Kit Installation Instructions
For this portable air conditioner to operate correctly, the hot air from
the back of the unit must be vented to the outside. Please follow
the instructions below for window kit installation.
1. Extend the exhaust hose at least 6” and insert it to the outdoor
exhaust hose outlet at the back of the air conditioner.
2. Attach the round connector to the opposite end of the exhaust
hose.
Exhaust
Hose
Rectangular
Connector
Adjustable Window
Panel
Window
Suction Cup
Round
Cover
Round
Connector
Suggested Tools- Phillips Screw Driver (Medium sized), Tape Measure/Ruler, Scissors,
Saw (In the event that your window panel needs to be cut down in size for installation).
NOTE: You may need to
contact your electrician if
your room’s circuit is not
able to
ower
our unit.
