4.0 VERIFYING AND TROUBLESHOOTING 5-2
4205 MAGNETOMETER INTERFACE 0021770_REV_A
3. Change drop down menu to Chan #5 (in the example).
Figure 5-3: Sonar Serial Port Menu
4. There should be no errors present in Sonar Toolbar and in the Serial Port Information window:
Figure 5-4: No Errors with Mag Data Scrolling
No Errors
Scrolling Mag Data
Serial Port Information Drop Down Menu
