SEASTAR and BAYSTAR Hydraulic Steering Systems
9-7
TRADITIONAL STYLE TILT HELM PUMPS
Tilt/Sport Tilt Helm Dimensions
SPORT TILT HELM PUMPS
4.8" (122mm)
9.2" (233.5mm)
6.8" (173mm)
2.4"
(61mm)
1.3" (33mm)
42°
6°
3" (76mm)
3.5" (89mm)
3.6" (91.5mm)
1/4" NPT PORTS (4)
2.75"
(70mm)
FILLER
PLUG
WOODRUFF KEY
3/4" STANDARD TAPER
4.45" dia
(114mm)
1/4" NPT PORTS (4)
DASH BOARD
4.37"
(111mm)
(42mm)
1.66
"
5.28"
(134mm)
5/8" NF THREAD
6.79" (175mm)
1.90"
3.60"
(91mm)
OUTLINE OF STEERING
WHEEL HUB
INCLUDES FITTING
CLEARANCE
4.92" (125mm)
2.67"
(68mm)
6.81" (173mm)
5.81" (148mm)
.88" (22mm)
4.00" dia
(102mm)
(48mm)
5.15" (131mm)
NOTICE
Max. steering wheel diameter 20" (508mm)
Max. steering wheel diameter 20" (508mm)
NOTICE
HELMS
Remote fill and vent kit (included with helm pump) requires a 3/4"
hole to be drilled into the dash board and above the helm pump.
Please refer to page 10-19, HA5450 for details.
NOTICE
NOTICE
Comes with
newly designed tilt
mechanism.
5
3
4
2
1
