10-4
Selection Guide
ITEM PART # QTY DESCRIPTION
7 Bulkhead Fitting Kit (2 fittings per Kit)
HF5512 1 3/4" Thick Bulkhead
HF5513 1 3" Thick Bulkhead
8 Bulkhead Fitting Kit (4 fittings per Kit)
HF5514 1 3/4" Thick Bulkhead
HF5515 1 3" Thick Bulkhead
ITEM PART # QTY DESCRIPTION
1 HO51__ 1 Hose Kit
2 HO51__ 1 Hose Kit
3 HO51__ 1 Hose Kit
4 HO51__ 2 Hose Kit
5 HO51__ 2 Hose Kit
6 HF5530 1 Tee Fitting (3 per Kit)
OUTBOARD HOSE
Single Station
Figure D: HC5345
Dual Front Mount Cylinders
Note: cylinder body moves
Figure E: HC5370
Dual Side Mount Cylinders
Note: cylinder body stationary
Figure F: HC535
Single Front Mount Cylinder
c/w bulkhead fittings
Note: cylinder body moves
Figure G: HC5370
Single Side Mount Cylinder
c/w bulkhead fittings
Note: cylinder body stationary
Figure H: HC5345
Dual Front Mount Cylinders
c/w bulkhead fittings
Figure I: HC5370
Dual Side Mount Cylinders
c/w bulkhead fittings
Figure A: HC5345
Single Front Mount Cylinder
Note: cylinder body moves
Figure B: HC5370
Single Side Mount Cylinder
Note: cylinder body stationary
Figure C: HC5380
Single Splashwell Mount Cylinder
Note: cylinder body stationary
