SEASTAR and BAYSTAR Hydraulic Steering Systems
3-7
OUTBOARD–FRONT MOUNT
Triple Engine Application Guide
A minimum of two cylinders will be required to operate a triple
engine installation with the exception of Mercury XS engines which
MUST use one cylinder per engine.
NOTICE
REVISION DATE: __________________
SEPT. 4th 2007
Is your Splashwell wide enough? Check page 3-11 for space requirements.
NOTICE
Use of incorrect components on a high speed/
performance boat, may lead to bending and breaking
of components r esulting in steering failure causing
property damage and/or personal injury.
Tournament Tiebar Cylinder should be used on ALL
Tournament/High Speed (60 Mph and above) multi-
engine boats. Please refer to page 3-8.
NOTICE
MFG YEAR MODEL CYL
PORT TO STARBOARD
NOTES
DRIVE CYL TO DRIVE CYL
FORCE 1995-DATE 90-120HP HC5345 HO6001 HO6002 See Note 4
HONDA 1996-DATE 75-90HP HC5345 HO6001 HO6002 See Note 2, 4
2001-DATE 135-225HP 4-Stroke HC5345 HO6003 HO6002 See Note 4
MERCURY 1989-DATE 75-275HP HC5345 HO5081 See Note 4
2003-DATE 250-300HP XS HC5345 HO6002 HO6002 See Note 3, 4
JOHNSON/ 1991-DATE 90-175HP HC5345 HO5080 See Note 4
EVINRUDE 1991-DATE 250-300HP HC5345 HO6001 HO6002 See Note 4
1991-DATE 200-225HP HC5345 HO6003 HO6002 See Note 4
1991-DATE 90-225HP Ficht HC5345 HO5080 See Note 2, 4
1998-DATE 65-70HP 4-Stroke HC5345 HO6003 HO6002 See Note 1, 4
2005-DATE E250 DPX Vindicator HC5348 HO6003 HO6002 See Note 4
SUZUKI 1986-DATE 150-200HP
2 & 4-Stroke
HC5345 HO6003 HO6002 See Note 4
1986-DATE 115-140HP HC5345 HO6003 HO6002 See Note 4
1998-DATE 65-70HP 4-Stroke HC5345 HO6001 HO6002 See Note 1, 4
2001-DATE 250-300HP HC5345 HO6001 HO6002 See Note 4
YAMAHA 1990-DATE 100-200HP HC5345 HO6001 HO6002 See Note 4
1990-DATE 225-250HP 4-Stroke HC5358 HO5080 See Note 4
1998-DATE 80-100HP 4-Stroke HC5358 HO6001 HO6002 See Note 4
2001-DATE 150-300HP HPDI HC5358 HO6001 HO6002 See Note 4
2006-DATE 350HP MUST Use Tournament Cylinders. See Note 3
Refer to Page 3-8
1. Requires Kit HO5090
2. Minimum Engine Center = 29"
The above engine applications are current through the revision date shown. For up-to-date engine applications go to: www.seastarsteerng.com
3. One cylinder required per engine. MUST use high strength tiller
bolt part # HA5822.
4. For high performance/speed applications, please refer
to the Caution noted at the bottom of this page.
WARNING
Prior to selecting a cylinder from this application guide, please refer
to page 3-4 to ensure that you are selecting the correct cylinder for
your engine/boat.
