5-2
Selection Guide
BOAT LENGTH PLANING HULL DISPLACEMENT HULL SAIL
UP TO SINGLE ENGINE TWIN ENGINE SINGLE ENGINE TWIN ENGINE SINGLE ENGINE
PLEASURE WORK PLEASURE WORK PLEASURE WORK PLEASURE WORK PLEASURE WORK
26FT (8m) 14 14242 444
32FT (10m) 24 14343 444
38FT (11.5m) 35 25553 545
44FT (13.5m) 5- 35--5 -5-
50FT (15m) -- 5---- ---
Application Guide
1. For systems 1,2&3-nylon tubing (3/8" dia.)
is the standard requirement for plumbing the
system. Copper tubing (3/8" dia.) can be sub-
stituted but Fitting Kit HF5507 is required.
(Refer to page 10-12).
2. For systems 4&5-copper tubing (3/8" dia.)
is the standard requirement for plumbing the
system. Fitting Kit HF5508 is required. (Refer
to page 10-12).
3. For systems 1, 2, 3, 4, & 5 Seastar outboard
hose can be substituted for nylon or copper
tube. These hoses must be ordered in stan-
dard lengths. They cannot be cut to length.
(Refer to page 10-2).
COMPONENT QTY MODEL PART # PAGE
DESCRIPTION REQ REF
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
CYLINDER 1 BA125 - 7ATM HC5312-2
OIL 3 SEASTAR OIL HA5430 11-1
TUBE 1 3/8" DIA NYLON (NOTE 1 & 3) HT5_ _ 10-6
FOR EXTRA STEERING STATION ADD:
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
FITTING KIT 1 ADD A STATION HF5502 10-11
OIL 1 SEASTAR HA5430 11-1
EXTRA TUBE 3/8" DIA NYLON (NOTE 1 & 3) 10-6
COMPONENT QTY MODEL PART # PAGE
DESCRIPTION REQ REF
HELM 1 ** SEASTAR II- STANDARD HH5272 9-6
CYLINDER 1 BA150 - 7TM HC5318
OIL 3 SEASTAR OIL HA5430 11-1
HOSE KIT 1 HOSE KIT HF5508 10-12
COPPER TUBE 3/8" DIA.(NOTE 2 & 3) 10-6
FOR EXTRA STEERING STATION ADD:
HELM 1 ** SEASTAR II- STANDARD HH5272 9-6
FITTING KIT 1 ADD A STATION HF5502 10-11
OIL 1 SEASTAR HA5430 11-1
EXTRA TUBE AS ABOVE (NOTE 2 & 3) 10-6
1 4
5
HELM 1 ** SEASTAR II- STANDARD HH5272 9-6
CYLINDER 1 BA175 - 7TM HC5319
OIL 3 SEASTAR OIL HA5430 11-1
HOSE KIT 1 HOSE KIT HF5508 10-12
COPPER TUBE 3/8" DIA.(NOTE 2 & 3) 10-6
FOR EXTRA STEERING STATION ADD:
HELM 1 ** SEASTAR II- STANDARD HH5272 9-6
10-11 OIL 1 SEASTAR HA5430 11-1
EXTRA TUBE AS ABOVE (NOTE 2 & 3) 10-6
2
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
CYLINDER BA135 - 7ATM HC5313
OIL 3 SEASTAR OIL HA5430 11-1
TUBE 1 3/8" DIA NYLON (NOTE 1 & 3) HT5_ _ 10-6
FOR EXTRA STEERING STATION ADD:
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
FITTING KIT 1 ADD A STATION HF5502 10-11
OIL 1 SEASTAR HA5430 11-1
EXTRA TUBE 3/8" DIA NYLON (NOTE 1 & 3) 10-6
3
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
CYLINDER 1 BA150 - 7ATM HC5314
OIL 3 SEASTAR OIL HA5430 11-1
TUBE 1 3/8" DIA NYLON (NOTE 1 & 3) HT5_ _ 10-6
FOR EXTRA STEERING STATION ADD:
HELM 1 * SEASTAR I- STANDARD HH5271 9-6
FITTING KIT 1 ADD A STATION HF5502 10-11
OIL 1 SEASTAR HA5430 11-1
EXTRA TUBE 3/8" DIA NYLON (NOTE 1 & 3) 10-6
BACK PLATE KIT (FOR STANDARD HELMS) HA5418 9-3
20 DEGREE WEDGE KIT (FOR STANDARD HELMS) HA5419 9-3
AUTOPILOT FITTING KIT (FOR ALL HELMS) HF5502 10-11
* TILT HELM-SEASTAR I HH5741 9-7
REAR MOUNT HELM-SEASTAR I HH5261 9-7
** TILT HELM-SEASTAR I HH5742 9-7
REAR MOUNT HELM-SEASTAR I HH5262 9-7
POWER ASSIST STEERING PA1200 2-1
a) Displacement Hull - maximum hull speed does not normally exceed 18 knots.
b) Planing Hull - maximum hull speed normally exceeds 18 knots.
ORDER GUIDE
4 TURNS LOCK TO LOCK
6 TURNS LOCK TO LOCK
5 TURNS LOCK TO LOCK
4-1/4 TURNS LOCK TO LOCK
5-1/2 TURNS LOCK TO LOCK
OPTIONAL EQUIPMENT
INBOARD STEERING
Want automotive type steering? Refer to page 2-1 for Power Assist Details.
NOTICE
If your vessel is beyond system 1 to 5, please go to page 7-1 for SeaStar
Power Steering Systems.
NOTICE
