6-2
Selection Guide
Components
H-21 .................................Hynautic 2.75 cu. in. helm (1" straight shaft)
or
H-25 .............................Hynautic 2.75 cu. in. helm (3/4" tapered shaft)
or
H-42 ...................................Hynautic 4.0 cu. in. helm (1" straight shaft)
or
H-42-02 ..........................Hynautic 4.0 cu. in. helm (3/4" tapered shaft)
or
H-41 ...................................Hynautic 5.5 cu. in. helm (1" straight shaft)
or
H-41-02 ..........................Hynautic 5.5 cu. in. helm (3/4" tapered shaft)
or
(See application guide page 6-3.)
HF-10.....................................................H-20 Fittings Kit for Main Station
HF-21.....................................................H-40 Fittings Kit for Main Station
HC53__ or K-_.................................................................Inboard Cylinder
(See application guide page 6-3. 1 or 2 required.)
R06............................................................Reservoir - Standard (2 quart)
MSV-21 ..................................................................Relief Valve (950 PSI)
MSVF-07 .............................................Relief Fittings (1150 & 1175-21-1)
MSVF-13..................................................Relief Fittings (1175-42-1 & up)
1/2" or 5/8" OD Copper Tubing............(See application guide page 6-3.)
HF5590 ...........................................Fitting Kit (for 1/2" Copper Tubing)
or
HF5592...............................................Fitting Kit (for 5/8" Copper Tubing)
(See application guide page 6-3. These fitting kits are for one
steering station, purchase add-a-station kit for 2nd station.)
HA5731 .......................................... Hose Kit for Copper Tubing (2 hoses)
Contains two 18" (.45m) hoses for single-cylinder installations.
HA5440 ................................................................ SeaStar Oil (1 Gallon)
(Other fittings may be required. Contact Teleflex Canada.)
Options
K-31 ............................................................ Pivot Mount Inboard Cylinder
(K-31 can be used in place of HC5378 or HC5379,
see application chart page 6-3 for details.)
HA5732 ........................................................ Dual Cylinder Hose 2' (.6m)
HA5733 ........................................................ Dual Cylinder Hose 3' (.9m)
HA5734 ...................................................... Dual Cylinder Hose 4' (1.2m)
HA5735 ...................................................... Dual Cylinder Hose 5' (1.5m)
HA5736 ...................................................... Dual Cylinder Hose 6' (1.8m)
These hoses are sold individually (four are
requir ed for dual cylinder installations).
R07 ................................................. Reservoir (2 quart, with hand pump)
R11 ................................................. Reservoir (1 quart, with hand pump)
R12 ........................................................................... Reservoir (2 quart)
MSV-19.................................................................. Relief Valve (500 PSI)
RV-55............................................... Reservalve (500 PSI, top read, 3/8)
RV-55P .............................. Reservalve (500 PSI, top read, 3/8, w/pump)
RV-57............................... Reservalve (500 PSI, top read, 5/16, w/pump)
RV-60............................................. Reservalve (950 PSI, top read, 5/16)
RV-67 ................................ Reservalve (950 PSI, frt.read, 5/16, w/pump)
HF-11 ................................................ H-20 Fittings Kit for Second Station
HF-22 ................................................ H-40 Fittings Kit for Second Station
3-LINE INBOARD STEERING
