SEASTAR and BAYSTAR Hydraulic Steering Systems
6-5
Reservoir Part# R-06
Capacity = 2 quarts.
Relief Valve Part# MSV-21
Relief Pressure factory set to
950psi.
3-LINE INBOARD STEERING
4-7/8"
(124mm)
9-1/2"
(241mm)
13-5/8"
(346mm)
1"
(25mm)
3-7/8"
(98.5mm)
2-1/2"
(63.5mm)
