TECHNICAL AND HEATING SPECIFICATIONS
Hopper capacity 27 kg
Efciency >90 %
Overall useable power 11,3 kW
Available power (min/max) 3/11,5 kW
Useable water power until 10 kW
Time between refuellings (min/max) 10/33 hours
Fuel consumption 0,8/2,7 kg/h
Minimum draught 12 Pa
Maximum pressure 1,5 bars
Heatable room totale * 320 m3
Weight including packaging (steel/ceramic) 176/187 kg
Smoke duct diameter 80 mm
Air intake pipe diameter 40 mm
* The heatable room dimensions are calculated assuming the use of pellets of the type described in the note, and home
insulation which complies with Italian law No. 10/91.
ELECTRICAL SPECIFICATIONS
Power supply 230Vac +/- 10% 50 Hz
On/off switch yes
Average power consumption 150 W
Average power consumption during ignition 400 W
Remote control frequency (optional extra) infrared
Protection on mains power supply fuse 2A, 250 Vac 5x20
Electronic circuit board protection fuse 2A, 250 Vac 5x20
The DEALER may install an optional device for remote on/off
operation, for example a dialler or room thermostat, on the AUX
port (clean voltagefree contact).
OPTIONAL EXTRAS
DIALLER (code 281900)
GSM dialler for pellet stoves, to turn on/off remotely with a
mobile phone text message.
REMOTE CONTROL (code 254160)
It is possible to buy a remote control to turn the
stove on and off and adjust it remotely.
ENGLISH
ENGLISH
MANDAT A ACQUA
120
90
CIRCOLATORE
ACQUA
LITHIUM
P40Pa
smoke RPM
WATER OUTLET
TEMPERATURE
DETECTOR
SMOKE EXTRACTION
MOTOR
SCREW FEEDER
MOTOR
WATER
CIRCULATION
PUMPE
230V AC
POWER SUPPLY
IGNITION ELEMENT
