- 40 -
DIMENSIONS ET HAUTEUR DES ÉVACUATIONS ET DES FIXATIONS
FRANÇAIS
FRANÇAIS
Ø 40 air
Ø 80 fumées
échappement vanne
de sécurité ½”
réintégration ½ “
refoulement ¾”
retour ¾”
Robinet évacuation
chaudière
Prise multi plot
RS 232
