- 58 -
DIMENSIONES Y ALTURAS DESCARGAS Y TOMAS
ESPAÑOL
ESPAÑOL
Ø 40 aire
Ø 80 humos
descarga válvula-
seguridad ½”
reingreso ½ “
ida ¾”
retorno ¾”
Grifo descarga
caldera
Toma serial
RS 232
