The above data are illustrative and are drawn from the certifi cation by a notifi ed body.
EDILKAMIN s.p.a. reserves the right to modify the product without notifi cation in the interests of improvement.
ELECTRICAL SPECIFICATIONS
Power 230 Vac +/- 10% 50 Hz
Mean absorbed power 50 - 80 W
Power absorption during ignition 300 W
Remote control frequency (provided) 2,4 GHz
Logic board protection Fuse 4 AT, 250 Vac 5x20
GENERAL INFORMATION
TECHNICAL CHARACTERISTICS per EN 14785
SLIDE 7 SLIDE
SLIDE
SLIDE 7
Nominal power Nominal power Reduced power
Available power
7,1 4,9 2,3 kW
Effi ciency 90,7 90,2 93,4 %
CO emissions at 13% O
2
0,010 0,008 0,032 %
Fumes temperature 144 126 82 °C
Fuel consumption 1,6 1,1 0,5 kg/h
Tank capacity 20 kg
Draw 11 11 10 Pa
Autonomy 13 18 40 ore
Heatable volume * 180 130 m
3
Fumes outlet diameter (female) 80 mm
Air intake diameter (male) 40 mm
Weight including packaging
steel 121
marbre 132
stone 128
glass 124
kg
TECHNICAL DATA FOR RATING THE FLUE
which must in any case satisfy the requirements of this sheet and the installation instructions for the product
SLIDE 7 SLIDE
SLIDE
SLIDE 7
Nominal power Nominal power Reduced power
Fumes temperature at outlet 173 151 99 °C
Minimum draw 0,01 Pa
Fumes fl ow rate 4,8 4,2 2 g/s
* The heatable volume is calculated based on the assumption of a heating demand of 33 Kcal/m³ hour.
*A calorifi c value of 4.8 kW/Kg has been used to calculate consumption
