34
ENGLISH
THERMOCOUPLE:
placed at the smoke outlet to detect the temperature.
Turns the stove on and off and controls its operation based on defined parameters.
AIR FLOW SENSOR:
placed in the air inlet channel.
This intervenes if an anomaly is detected in the combustion air flow and causes insufficient circulation in the smoke ducts.
SAFETY THERMOSTAT:
trips when the temperature inside the stove is too high. It stops pellet loading, causing the stove to go out.
SAFETY DEVICES
THERMOTECHNICAL CHARACTERISTICS
Nominal power
9
kW
Efficiency nominal power
94,1
%
Emissions CO (13% O
2
) nominal power
149
ppm
Smoke mass nominal power
5,8
g/s
Reduced power
2,8
kW
Efficiency reduced power
96,2
%
Emissions CO (13% O
2
) reduced power
206
ppm
Smoke mass reduced power
2,1
g/s
Maximum overheated smoke
111
°C
Minimum draught
12 / 5
Pa
Autonomy (min/max)
9 / 28
hours
Fuel consumption (min/max)
0,6/2
kg/h
Hopper capacity
20
kg
Heatable volume
*
235
m
3
Weight including packaging
(Tiny/Kelly)
217/189
kg
Smoke outlet pipe diameter (male)
80
mm
Air intake pipe diameter (male)
40
mm
* The heatable room dimensions are calculated on the basis of pellets with an lhv of at least 4300 kcal/kg and home insulation in
compliance with Italian law 10/91, and subsequent changes together with an expected heat output of 33 Kcal/m³ per hour.
* It is also important to consider the position of the stove in the room to be heated.
ELECTRICAL CHARACTERISTICS
Power supply 230Vac +/- 10% 50 Hz
Average power consumption 100 W
Power consumption during ignition 400 W
Remote control frequency (optional) Infrared
Remote control frequency (as standard) Radio waves 2.4 GHz
Protection on electronic circuit board 2AT, 250 Vac, 5x20 Fuse
The data shown above is purely indicative.
EDILKAMIN s.p.a. reserves the right to make changes to these products to improve their performance with
no prior warning.
FEATURES
